Specifications
Image Sensor
Style PTZ,
Sensor CMOS,
Sensor Size 1/4 Inch Color CMOS Sensor,
Resolution 1.0 Megapixels,
Lens (mm) 3.6,
Viewing Angle (Degree) 60,
Minimum Illumination (Lux) 0.1,
Video Image/Audio Setting
Compression H.264,
Video Frame Rate (FPS) 25,
Refresh Rate 60HZ, 50HZ,
Video Adjustment Auto Backlight Compensation, Auto White Balance, Contrast Adjustable, Brightness Adjustable,
OSD Yes,
Audio Output External Speaker,
Audio Input Built-in Mic,
Audio Compression Standard ADPCM,
Communication&Interface
Network Interface Wi-Fi/802.11/b/g, RJ-45 10/100Mb self-adaptable Ethernet slot,
Supported Protocol DHCP, TCP/IP, FTP, PPPoE, UPNP, DDNS, HTTP, SMTP,
Wireless Security WPA2, WPA, WEP,
IP Mode Static IP address, Dynamic IP address,
Maximum SD Card Support (GB) 32GB,
DDNS (Free) Yes,
Alarm Input 1 On/Off Input,
Alarm Output 1 Relay Output,
Alarm Action Email Photo, FTP Photo,
Physical/Environment
Environment Indoor,
Power Supply (V) DC5V/2A,
Power Consumption (W) 5.5W,
Operate Temperature (℃) -10° ~ 55°C,
Storage Temperature (℃) -10°C ~ 60°,
Humidity (%) RH 20% ~ 85% ,
Size (L x H x W, mm) 105*100*130,
Weight (g) 800,
System Requirment
Supported Mobile Systems Android, Windows Mobile, Symbian, iPhone OS,
Supported Operating Systems Microsoft Windows 2000, Microsoft Windows ME, Microsoft Windows 98, Microsoft Windows 7, Microsoft Windows Vista, Microsoft Windows XP,
Supported Browers Other Standard Browser, Google Chrome, Firefox, Safari, IE,
Client Software Yes,
Additional Features
Features Plug and play, Wi-Fi Protected Setup, IR-cut, Remote Access, Dual Stream, Motion Detection, Day Night,
IR Night Vision Distance (m) 10-15,
Two-way
